Description
| Wire type and power | AC 2-wire type 100-240VAC~ |
|---|---|
| Sensing side size | Frame size 30mm |
| Sensing distance | 15mm |
| Standard sensing target | 45×45×1mm(iron) |
| Response frequency | 20Hz |
| Current specification | Leakage current: Max. 2.5mA |
| Control output | Normally Open |
| Sensing type | Standard type(front sensing type) |
| Material | Heat-resistant ABS |
| Protection structure | IP67 |
| Environment_Ambient temperature | -25 to 70℃, storage: -30 to 80℃ |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Hysteresis(distance) | Max. 10% of sensing distance |
| Weight | ≈ 92g (≈ 161g) |
