Description
| Wire type and power | DC 4-wire type 12-48VDC  |
|---|---|
| Sensing side size | Frame size 80mm |
| Sensing distance | 50mm |
| Standard sensing target | 150×150×1mm(iron) |
| Response frequency | 30Hz |
| Current specification | Current consumption: Max. 20mA |
| Control output | PNP Normally Open+Normally Closed |
| Sensing type | Upper sensing type |
| Protection structure | IP67(IEC standard) |
| Environment_Ambient temperature | -25 to 70℃, storage: -30 to 80℃ |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Hysteresis(distance) | Max. 15% of sensing distance |
| Weight | Approx. 470g |
